Fire Extinguishing Systems Model / Size Chart MA Series HFC-227ea
WARNING: Craft with equipment that draws intake air from within a protected space require installation of an Engine Shutdown System.
MA2 Size Chart
| Volume Protected | Diameter | Total Height | Agent Weight | Shipping Weight | System Pressure(@70° F) | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model Number | ft³ | m³ | in | mm | in | mm | lbs | kgs | lbs | kgs | psi |
| MA20025227-BL | 25 | 0.7 | 3.3 | 85 | 9.5 | 241 | 1.1 | 0.5 | 5 | 2.4 | 240 |
| MA20050227-BL | 50 | 1.4 | 3.3 | 85 | 13.3 | 338 | 2.2 | 1 | 8 | 3.7 | 240 |
| MA20075227-BL | 75 | 2.1 | 4.3 | 110 | 15.6 | 396 | 3.2 | 1.5 | 13 | 6 | 240 |
| MA20100227-BL | 100 | 2.8 | 4.3 | 110 | 15.6 | 396 | 4.3 | 2 | 14 | 6.4 | 240 |
| MA20125227-BL | 125 | 3.5 | 4.3 | 110 | 15.6 | 396 | 5.4 | 2.5 | 15 | 6.9 | 240 |
| MA20150227-BL | 150 | 4.3 | 5.1 | 130 | 17.2 | 436 | 6.5 | 2.9 | 20 | 9.2 | 240 |
| MA20175227-BL | 175 | 4.9 | 5.1 | 130 | 17.2 | 436 | 7.6 | 3.4 | 21 | 9.6 | 240 |
| MA20200227-BL | 200 | 5.7 | 5.1 | 130 | 17.2 | 436 | 8.6 | 3.9 | 22 | 10 | 240 |
| MA20225227-BL | 225 | 6.4 | 6.3 | 160 | 17.3 | 439 | 9.7 | 4.4 | 29 | 13.2 | 240 |
| MA20250227-BL | 250 | 7 | 6.3 | 160 | 17.3 | 439 | 10.8 | 4.9 | 30 | 13.6 | 240 |
| MA20275227-BL | 275 | 7.8 | 6.3 | 160 | 17.3 | 439 | 11.9 | 5.4 | 31 | 14.1 | 240 |
| MA20300227-BL | 300 | 8.5 | 6.3 | 160 | 17.3 | 439 | 13 | 5.9 | 32 | 14.5 | 240 |
| MA20325227-BL | 325 | 9.2 | 7.1 | 180 | 17.2 | 437 | 14 | 6.4 | 37 | 16.9 | 240 |
| MA20350227-BL | 350 | 10 | 7.1 | 180 | 17.2 | 437 | 15.1 | 6.9 | 38 | 17.4 | 240 |
| MA20375227-BL | 375 | 10.6 | 7.1 | 180 | 17.2 | 437 | 16.2 | 7.4 | 39 | 17.8 | 240 |
| MA20400227-BL | 400 | 11.3 | 7.1 | 180 | 19.4 | 493 | 17.3 | 7.9 | 43 | 19.5 | 240 |
| MA20450227-BL | 450 | 12.7 | 7.1 | 180 | 19.4 | 493 | 19.4 | 8.8 | 45 | 20.4 | 240 |
| MA20500227-BL | 500 | 14.1 | 7.1 | 180 | 27.4 | 696 | 21.6 | 9.8 | 55 | 24.8 | 240 |
| MA20550227-BL | 550 | 15.6 | 7.1 | 180 | 27.4 | 696 | 23.8 | 10.8 | 57 | 25.7 | 240 |
| MA20600227-BL | 600 | 17 | 7.1 | 180 | 27.4 | 696 | 25.9 | 11.8 | 60 | 27 | 240 |
| MA20650227-BL | 650 | 18.4 | 7.1 | 180 | 27.4 | 696 | 28.1 | 12.8 | 62 | 28.3 | 240 |
| MA20700227-BL | 700 | 19.8 | 7.1 | 180 | 27.4 | 696 | 30.2 | 13.7 | 64 | 29.2 | 240 |
| MA20750227-BL | 750 | 21.2 | 7.1 | 180 | 33.3 | 846 | 32.4 | 14.7 | 70 | 31.6 | 360 |
| MA20800227-BL | 800 | 22.6 | 7.1 | 180 | 33.3 | 846 | 34.5 | 15.6 | 73 | 33 | 360 |
| MA20850227-BL | 850 | 24 | 7.1 | 180 | 33.3 | 846 | 36.7 | 16.7 | 76 | 34.3 | 360 |
| MA20900227-BL | 900 | 25.5 | 7.1 | 180 | 33.3 | 846 | 38.9 | 17.7 | 77 | 35.1 | 360 |
| MA20950227-BL | 950 | 26.9 | 7.1 | 180 | 33.3 | 846 | 41 | 18.7 | 80 | 36.4 | 360 |
| MA21000227-BL | 1000 | 28.3 | 10 | 254 | 21.4 | 544 | 43.2 | 19.6 | 93 | 42.2 | 360 |
| MA21050227-BL | 1050 | 29.7 | 10 | 254 | 21.4 | 544 | 45.3 | 20.5 | 96 | 43.5 | 360 |
| MA21100227-BL | 1100 | 31.1 | 10 | 254 | 21.4 | 544 | 47.5 | 21.6 | 99 | 44.9 | 360 |
| MA21150227-BL | 1150 | 33 | 10 | 254 | 27.5 | 699 | 49.7 | 22.6 | 108 | 49 | 360 |
| MA21200227-BL | 1200 | 34 | 10 | 254 | 27.5 | 699 | 51.8 | 23.6 | 111 | 50.3 | 360 |
| MA21250227-BL | 1250 | 35.4 | 10 | 254 | 27.5 | 699 | 54 | 24.5 | 113 | 51.3 | 360 |
| MA21300227-BL | 1300 | 36.8 | 10 | 254 | 27.5 | 699 | 56.1 | 25.4 | 116 | 52.6 | 360 |
| MA21350227-BL | 1350 | 38.2 | 10 | 254 | 27.5 | 699 | 58.3 | 26.5 | 119 | 54 | 360 |
| MA21400227-BL | 1400 | 39.6 | 10 | 254 | 27.5 | 699 | 60.5 | 27.5 | 121 | 54.9 | 360 |
| MA21450227-BL | 1450 | 41 | 10 | 254 | 27.5 | 699 | 62.6 | 28.5 | 124 | 56.2 | 360 |
| MA21500227-BL | 1500 | 42.5 | 10 | 254 | 27.5 | 699 | 64.8 | 29.5 | 126 | 57.2 | 360 |
| Low Profile Models | 360 | ||||||||||
| MA20750227-BL4 | 750 | 21.2 | 10 | 254 | 21.4 | 544 | 32.4 | 14.7 | 80 | 36.3 | 360 |
| MA20800227-BL4 | 800 | 22.6 | 10 | 254 | 21.4 | 544 | 34.5 | 15.6 | 83 | 37.6 | 360 |
| MA20850227-BL4 | 850 | 24 | 10 | 254 | 21.4 | 544 | 36.7 | 16.7 | 86 | 39 | 360 |
| MA20900227-BL4 | 900 | 25.5 | 10 | 254 | 21.4 | 544 | 38.9 | 17.7 | 88 | 39.9 | 360 |
| MA20950227-BL4 | 950 | 26.9 | 10 | 254 | 21.4 | 544 | 41 | 18.7 | 91 | 41.3 | 360 |
WARNING: Diesel-powered craft requires the installation of an Engine Shutdown System.
